Internal Dimension
Length 5,898 mm 19 ft 4.20 in
Width 2,352 mm 7 ft 8.59 in
Height 2,393 mm 7 ft 10.22 in
Door Opening
Width 2,340 mm 7 ft 8.13 in
Height 2,280 mm 7 ft 5.77 in
Weight
Max
Gross		 30,480 (24,000) kg 67,200 (52,910) lb
Tare 2,200 (2,290) kg 4,850 (5,050) lb
Max Payload 28,280 (21,710) kg 62,350 (47,860) lb
Load Capacity
  33.2 cubic meters 1,173 cubic feet
Internal Dimension
Length 12.032 mm 39 ft 5.70 in
Width 2,352 mm 7 ft 8.59 in
Height 2,393 mm 7 ft 10.22 in
Door Opening
Width 2,340 mm 7 ft 8.13 in
Height 2,280 mm 7 ft 5.77 in
Weight
Max Gross 32,500 (30,480) kg 71,650 (67,200) lb
Tare 3,620 (3,770) kg 7,980 (8,310) lb
Max Payload 28,880 (26,710) kg 63,670 (58,890) lb
Load Capacity
  68.0(67.4) cubic meters 2,385(2,379) cubic feet
Internal Dimension
Length 5,893(5,898) mm 19 ft 4.01 in
(19 ft 4.21 in)
Width 2,346 mm 7 ft 8.36 in
Height 2,362(2,381) mm 7 ft 9 in
(7 ft 9.74 in)
Door Opening
Width 2,337 mm 7 ft 8.01 in
Height 2,280(2,244) mm 7 ft 5.76 in
(7 ft 4.35 in)
Weight
Max
Gross		 30,480 (24,000) kg 67,200 (52,910) lb
Tare 2,320 (2,390~2,450) kg 5,120 (5,400) lb
Max
Payload		 28,160 (21,550~21,610) kg 62,080 (47,510) lb
Load Capacity
32.7 cubic meters 1,153 cubic feet
Internal Dimension
Length 11,986(11,652) mm 39 ft 3.89 in
(38 ft 2 in)
Width 2,236(2,374) mm 7 ft 4.03 in(7 ft 9.4 in)
Height 1,968(2,364) mm
High Cube [2,264mm]		 6 ft 5.48 in(7 ft 5 in)
High Cube [7.42ft]
Weight
Max Gross 45,000(50,000) kg 99,210(110,230) lb
Tare 5,980(5,250) kg 13,183(11,570) lb
Max Payload 39,020(44,750) kg 86,023(98,650) lb
Internal Dimension
Length 11,588 mm 38 ft 0.22 in
Width 2,290 mm 7 ft 6.16 in
Height 2,557.5 mm 8 ft 4.69 in
Door Opening
Width 2,294 mm 7 ft 6.31 in
Height 2,569 mm 8 ft 5.14 in
Weight
Max Gross 34,000 (30,480) kg 74,960 (67,200) lb
Tare 4,600 (4,800) kg 10,140 (10,580) lb
Max Payload 29,400 (25,680) kg 64,815 (56,620) lb
Load Capacity
  67.9 cubic meters 2,400 cubic feet
Internal Dimension
Length 13,556 mm 44 ft 5.69 in
Width 2,352 mm 7 ft 8.59 in
Height 2,698 mm 8 ft 10.22 in
Door Opening
Width 2,340 mm 7 ft 8.13 in
Height 2,585 mm 8 ft 5.77 in
Weight
Max Gross 32,500 (30,480) kg 71,650 (67,200) lb
Tare 4,880 kg 10,760 lb
Max Payload 27,620 (25,600) kg 60,890 (56,440) lb
Load Capacity
  86.0 cubic meters 3,040 cubic feet

Internal Dimension

Length

5,456 mm

17 ft 10.80 in

Width

2,290 mm

7 ft 6.16 in

Height

2,262 mm

7 ft 5.06 in

Door Opening

Width

2,290 mm

7ft 6.16 in

Height

2,251 mm

7 ft 4.63 in

Weight

Max Gross

30,480 (24,000) kg

67,200 (52,910) lb

Tare

2,930 (2,960) kg

6,460 (6,530) lb

Max Payload

27,550 (21,040) kg

60,740 (46,380) lb

Load Capacity



28.3 cubic meters

998 cubic feet
